Technical table

name	value
Ball diameter (mm)	5
Centre styli	false
Effective working length (mm)	91
Holder material	Stainless steel
Overall length (mm)	100
Stem diameter (mm)	3
Stem material	Tungsten carbide
Thread	M5
Tip material	Ruby

Description

Straight styli are designed to inspect simple features where direct, unobstructed contact with a measured surface is possible. A tungsten carbide stem provides exceptional rigidity, particularly for styli with small ball and stem diameters. Ruby is regarded as the industry standard for stylus tips. It is one of the hardest materials available and suitable for most applications. Due to adhesive pickup, ruby tips are not recommended for scanning aluminium parts.

Equivalent to

Equivalent to Q-Mark part number: ATG-50102.5-DS3

Technical documentation

Technical document 1 (DOC)

Download

Related products

$147.20

M5 Ø6 mm ruby ball, carbon fibre stem, L 100 mm, EWL 90.1 mm

Part number: A-5003-5260

$128.80

M5 Ø6 mm ruby ball, carbon fibre stem, L 100 mm, EWL 58.9 mm

Part number: A-5003-5259

$146.16

M5 Ø6 mm ruby ball, carbon fibre stem, L 50 mm, EWL 39.5 mm

Part number: A-5003-5237

$130.94

M5 Ø5 mm ruby ball, tungsten carbide stem, L 50 mm

Part number: A-5003-5236

$84.00

M5 Ø5 mm ruby ball, tungsten carbide stem, L 30 mm, EWL 21.5 mm

Part number: A-5003-5220

Explore variants

48 products found

Explore variants

M5 Ø5 mm ruby ball, tungsten carbide stem, L 100 mm, EWL 50 mm
$119.60
Part numberA-5003-5257
Lead times can vary for this product. Contact us for more information.
