Screw pusher clamp for use with M6, M8 and 1/4-20 base plates

Part number: R-CSP

$121.28

Screw pusher clamp for use with M6, M8 and 1/4-20 base plates - 1

Screw pusher clamp for use with M6, M8 and 1/4-20 base plates - 2

Screw pusher clamp for use with M6, M8 and 1/4-20 base plates - thumbnail 1

Screw pusher clamp for use with M6, M8 and 1/4-20 base plates - thumbnail 2

Stocked item - Dispatched between 2-3 working days.

Quantity

The screw pusher clamp is used to push a part against a support structure by screwing the thumbscrew in or out to release pressure on the part. It is recommended for use on CMMs, t... Read more

Free shipping on orders over $500.00.

Create account or sign in for faster checkout.

Buy direct or request a quote.

Technical table

Description

Equivalent to

Technical documentation

Technical table

name	value
Adjustable (mm)	17.8
Clamp type	Push clamp
Fixture type	Push clamp
Height (mm)	76.2
Length (mm)	76.2
Length (in)	3
Measurement system	Multiple
Slot height (mm)	44.4
Slot length (mm)	44.5
Thread	Multiple
Width (mm)	25.4
Width (in)	1

Description

The screw pusher clamp is used to push a part against a support structure by screwing the thumbscrew in or out to release pressure on the part. It is recommended for use on CMMs, the Equator™ gauging system, and vision and multi-sensor machines.

This is a universal component suitable for thread sizes M6, M8 and ¼-20.

Note: Included: socket head cap screws and washers.
