Micro centres with Ø4.8 mm pins and M4 thread

Part number: R-CMC-4
$217.35
Micro centres with Ø4.8 mm pins and M4 thread - 1
Micro centres with Ø4.8 mm pins and M4 thread - 2
Micro centres with Ø4.8 mm pins and M4 thread - thumbnail 1
Micro centres with Ø4.8 mm pins and M4 thread - thumbnail 2
Quantity

These micro centres are ideal for holding cylindrical parts up to 26 mm in length and 25.5 mm in diameter. They are recommended for use on vision and multi-sensor machines. Read more

Free shipping on orders over $500.00.
Create account or sign in for faster checkout.
Buy direct or request a quote.
Technical table
Description
Technical documentation

Technical table

Adjustable (mm)26
Clamp typeCentres
Height (mm)30
Length (mm)50.8
Measurement systemMetric
Pin diameter (mm)4.8
Pin height (mm)12.7
ThreadM4
Width (mm)31.8

Description

These micro centres are ideal for holding cylindrical parts up to 26 mm in length and 25.5 mm in diameter. They are recommended for use on vision and multi-sensor machines.

Note: Included: socket head cap screws.

Technical documentation

Technical document 1 (DOC)
Download
